2.0T Servo Motor Copper Wire Splice Machine EW-1550

Price of the selected optionon request
Delivery options

Description

Feature

● With pressure detecting device that automatically detects the quality of the crimped product and can export the crimped data for analysis.

● The mould monitor is used to control the quality of the crimping, which allows the operator to visually observe the position of the product.

● With automatic conveying of copper strip, the material is automatically cut, formed, pressed, and no waste is generated, saving costs.

Specifications

Model
EW-1550
Splice force
2.0T (can adjust)
Splice time
0.01S (can adjust keep crimp time)
Stop splice machine
Can adjust
Motor rating
0.75KW Sevo motor
Power supply
AC220 110V /50 60HZ
Wire diameter
AWG24#-AWG10#
Feeding length parameters
1mm-99.9mm
Cooper width
1.0-6.0mm
splice precision
0.1-0.2(±0.05m)
Dimensions
340*360*450mm
Crimp Pull Power
within 16KGS
Weight
60KGS
Application for 2.0T Servo Motor Copper Wire Splice Machine EW-1550
