Feature
● Dual-Station Independent Processing: Engineered to handle and feed two entirely distinct wire or cable strands simultaneously. Each raw material pathway operates completely independent of the other, boosting line versatility for multi-wire workstations.
● Dual-Motor Dedicated Drive Architecture: Both wire spool stations are backed by individual, high-torque 180W electric motor assemblies, delivering strong, continuous pulling force straight from heavy storage racks or deep feeding barrels.
● Infinitely Variable Demand-Feed Sync: Integrated with a smart electronic sensor control system. The rotation velocity automatically self-adjusts in real-time to match the instantaneous material consumption rate of any downline cutting or crimping equipment, removing the need for manual speed setting changes.
● Constant Low-Tension Payout Loop: Provides a highly stable, uniform feeding tension profile across both wire lines, completely isolating fragile conductors from violent mechanical jerks to prevent physical linear deformation or insulation stretching.
● Heavy-Duty Standalone Stability: Built on a robust, free-standing vertical chassis measuring 500 by 500 by 900 mm. The structure safely supports a maximum aggregated loading weight up to 15 KGS while resisting operational tipping.
Application Range
● High-Speed Cutting & Stripping Upgrades: The essential auxiliary integration for standalone microcomputer cutting-stripping machines, ensuring that erratic heavy spool inertia does not compromise wire cutting accuracy.
● Automotive & Consumer Electronics EMS Lines: Deployed across fast-paced Electronics Manufacturing Services (EMS) facilities to feed parallel color wires into dual-head terminal crimpers or housing insertion stations. (Highly targeted at contract manufacturing corridors in Mexico, Vietnam, Thailand, Poland, and India).
● Precision Sensor & Multi-Core Shielded Loom Prepping: Safely pre-feeds delicate, low-tolerance signal wires and multi-conductor sheathed cables that are highly vulnerable to stretching under manual or passive tension.
