Feature
● Deformation-Free Tube & Hose Payout: Specifically designed for soft, crushable, and flexible materials like corrugated tubing, heat-shrink sleeves, PVC hoses, and silicone lines up to 30 mm OD.
● Smart Inverter-Driven Speed Synchronization: Equipped with an intelligent multi-speed frequency inverter linked to an accumulator (wire storage) dancer arm. Automatically accelerates, decelerates, or stops rotation based on downstream material consumption.
● Adjustable Counterweight Tension System: Features a simple counterweight adjustment system on the dancer arm, allowing operators to fine-tune material tension to suit delicate thin-walled tubes or rigid wire materials.
● Heavy-Duty Carbon Steel Construction: Fabricated from thick, high-grade carbon steel for long-term structural rigidity, vibration absorption, and reliable continuous industrial operation.
● Versatile Spool & Drum Accommodation: Supports spools with outer diameters up to 800 mm, inner arbor holes of 250 mm, and reel widths up to 800 mm, with a maximum load capacity of 30 kg.
Application Range
● Automotive Wire Harness Protection: Smooth unspooling of split and non-split corrugated tubes, heat-shrink sleeves, and braided jackets for cutting lines.
● Medical & Food-Grade Tubing Processing: Tension-free payout of soft silicone, polyurethane, and PVC hoses without flattening or stretching the profile.
● Industrial Hose & Fluid Line Assembly: Feeding flexible pneumatic hoses, cooling lines, and low-pressure fluid conduits into high-speed length-cutting equipment.
● Light-to-Medium Electrical Wiring: Pre-feeding flexible cables, multi-core leads, and insulated wire spools up to 30 kg.
