Wire Processing and Electrical Installation Equipment

Electric Cable Wire Brushing and Twisting Machine(0.1-2 mm²) EW-10WT-1

Price of the selected optionon request
Delivery options

Description

Feature

Cable Shield Braid Twisting Machine is mainly used for twisting the outside braid of shielded cable.

● It can twist cable braid layer all-in-one and brushing cables.

● The speed is controllable. and the performance is stable.

● It is a common and necessary equipment for wire harness processing.

● It can be used for processing different kinds of ground cables, braided cables, shielded cables etc.

Specifications

Model
EW-10WT-1
Stripping length
5—80mm (Can be customized to 150mm)
Stripping range
0.1-2 mm²
Air Pressure
1.5-2.5kg/cm2
Voltage
220V/110V/50HZ/60HZ
Motor Power
10W / 1400RPS
Weight
12KGS
Size
L340*W220*H210mm
Application for Electric Cable Wire Brushing and Twisting Machine(0.1-2 mm²) EW-10WT-1
