Hard Pipe Cutting Machine (rotary blades) EW-12H

Price of the selected optionon request
Delivery options

Description

Feature

● The machine is designed for cutting hard tubular materials such as PVC, PE, PPR.

● Equipped with rotary blades and latest control system.

● Memory capacity of 100 materials.

● High productivity, which can be up to 1000 pcs./h.

● The machine will stop cutting if the material is used out, owing to the material detection device.

● Intelligent sensor --- the machine will not start to cut until the safety door is closed.

● Optional device to connect to pipe making machine.

Specifications

Model
EW-12H
Material
PVC, PE, PPR
Material outer diameter
1 - 50 mm(can be customized)
Cutting length
1 - 99,999.9 mm
Cutting increment
0.1 mm
Cutting length tolerance
0.001 * L ± 0.2 mm (PVC, L < 1000 mm)
Cutting mode
Rotary cutting
Control mode
PLC
Type of feeding motor
Stepping motor
Rotary speed of cutting blades
Adjustable
Productivity
1000 pcs./H (depending on material
Additional information
andcutting length)
Power supply
110, 220 V (50 - 60 Hz)
Power
750 W
Weight
80 kg
Dimension
540 * 560 * 570 mm
Application for Hard Pipe Cutting Machine (rotary blades) EW-12H
