Glue Dispensing FeatureIt runs alternately with a double platform, saving the time for the product to be taken and put.It is independent of the mold. It is an aluminum profile casting structure with beautiful appearance.It has a hand-held teaching programmer, which is fast and easy to program.Its glue speed and glue amount can be set separately.It is controlled by a high precision stepping motor, and the trail is accurate.It can finish any shape point glue, such as space point, line, arc, etc.It contains a variety of glue needles, syringes, glue valves and controllers to meet different requirements.ModelYK-D331Dimension (L*W*H) (mm)620*585*696 mmWeight(kg)68 KGOperation Range (X*Y*Z) (mm)300*300*100mmAxes3 Axis (X, Y, Z)Drive modeDouble guide rail synchronous beltPower sourceStepper motorMaximum speed500mm/secRepeat accuracy±0.05mmMaximum loadSynchronous belt: X/Y/Z 5kg/5kg/3kg Screw:...
