Product Introduction Features Self-developed semi-automatic system for automatic wire harness welding. High-power imported ultrasonic generator ensures stable performance. Parameterized height adjustment for simplified operation. Customizable welding heads for specific cable types. Reserve MES hardware interface. Multi-parameter monitoring(time, energy, pressure, amplitude, etc.). Ultrasonic Welding Machine WG-JH605 Model: WG-JH605 Operating Frequency 20KHz Dimensions 1200*960*2020 mm Input Voltage AC 380V 50Hz Cable Cross-Section Range 10mm²-50mm² Power 6200W Weight 660kg Air Pressure Supply 0.5MPa-0.6MPa Display Integrated Touchscreen Industrial Computer Alarm & Monitoring Welding Result Monitoring(welding time, energy, pressure, amplitude, power, pre/post-weld height.) Interface Display Time, energy, pressure, amplitude, power, frequency, cycle count. Production Efficiency 1.5...
